PMU Change Log (Incl. Tested Version)
我們一直不斷的進行更完善的功能更新以及問題修復,目的是希望能提供更棒更優異的使用體驗,以下更新記錄包含了先行版(測試版),對此可能會有部分功能不穩定,如遇到使用上的功能問題,請聯繫客服並嘗試退回之前的版本進行使用。
Service Mail : tech@tag-parts.com
2023.08.09 Client: 85.1 release candidate (RC) Firmware: 85.1 release candidate (RC)
Firmware:
- Hardware compatibility:
- Added support for PMUs-16 with updated accelerometer/gyroscope hardware component (same functionality as earlier) — devices with serial numbers xxx-2329-xxxxx or later
- Fixes:
- ECUMASTER CANbus keyboards:
- A correct color is now selected when ‘First State’ is set to ‘1’ with the ‘Latching Switch’ button type
Client:
- Fixes:
- Fixed a bug that prevented the firmware from being upgraded on the first attempt.
- Fixed a bug with real-time logging that sometimes didn’t start after a firmware upgrade
2023-05-22 Client: 83.2 beta Firmware: 83.2 beta
Firmware:
- Fixes:
- ECUMASTER CAN Keyboards: LED lights are now working correctly, even with the keyboard firmware v2.23.
- New features:
- ECUMASTER CAN Keyboards: New channel “kb_X.active” added to CANbus Keyboards. It’s ‘1’ when a keyboard is active
Client:
- Improvements:
- Performance improvements of the CSV export
- Fixes:
- Application now properly checks the Table Memory limit when duplicating a Table
- Fixed the issue with the preview of the CSV not generating properly
- Fixed the issue with the CSV export crashing in case of large file
2022-10-24 Client: 83.0 experimental / Firmware: 83.0 experimental
Firmware:
- New features:
- Added support for ‘5×3 Ecumaster (7 colors)’ keypad
Client:
- Fixes:
- Keyboard dialog: “Order buttons” is now functioning correctly.
- Changes:
- Project files created with this PMU client version cannot be loaded to an older version of the software. Please backup your projects before installing.
CAN Streams:
- BatteryIsolator.canx – updated for firmware 3.0 (or later) of BatteryIsolator
2022-09-19 Client: 82.2 experimental / Firmware: 82.2 experimental
Firmware:
- Fixes:
- CANbus Inputs are now functional after restarting a device. (Fixed bug from version 82.1).
2022-09-01 Client: 82.1 experimental / Firmware: 82.1 experimental
Firmware:
- New features:
- More CANbus Message Objects – 50 shared by CAN1 and CAN2 (up from 8+8)
- Increased number of CANbus Inputs to 150 (up from 100)
- Support for CAN Inputs located across 3 bytes (e.g. endian=little, bitCount=13, bitPosition=13)
- Custom multiplexer for compound CAN frames – any bitPosition and bitCount up to 16 bits
- Possible to read normal and compound inputs from one CAN frame
- Support for ‘Motec M800 Set1’ CAN stream
- CANbus Export: DLC can be specified
- Improvements:
- CAN frame with wrong DLC (e.g. 15) is now treated as DLC=8 (solution for GET_H4FSAE ecu)
- Changes:
- CANbus Message Objects timeout works for all frames at once, not for individual frames like
before
- CANbus Message Objects timeout works for all frames at once, not for individual frames like
Client:
- Improvements:
- DBC Importer: support for custom multiplexer for compound CAN frames
- USBtoCAN.DLL updated to 15.3 with stability improvements
- Changes:
- Project files created with this PMU client version cannot be loaded to an older version of the
software. Please backup your projects before installing.
- Project files created with this PMU client version cannot be loaded to an older version of the
CAN Streams:
- New:
- Motec_M800_Set1.canx
2022-08-31 Client: 57.3.2 / Firmware: 57.3
Client:
- Improvements:
- Keyboard focus when editing a cell of a Table has been improved.
- Fixes:
- Random program crash when editing a Table has been corrected.
2022-08-26 Client: 57.3.1 / Firmware: 57.3
Notes:
- The firmware 57.3 and 57.3-beta are exactly the same firmware.
Client:
- Fixes:
- Axes of tables are no longer corrupted when deleting/moving some other channels of the same
type
- Axes of tables are no longer corrupted when deleting/moving some other channels of the same
CAN Streams:
- New:
- Microtech.canx
- Haltech_TMS.canx
- Updated:
- Megasquirt2&3.canx – channels ‘canout1’ .. ‘canout8’ added
- Fixed:
- KMS.canx – it’s working again with the PMU
2022-04-29 Client: 57.3 beta / Firmware: 57.3 beta
Firmware:
- New features:
- PMU16-AS standard stream: status of 6 low-side outputs added (frame 0x668 (default)):
- byte 6: 0x01 – l1.active, 0x02 – l2.active, 0x04 – l3.active, etc
- byte 7: 0x01 – l1.error, 0x02 – l2.error, 0x04 – l3.error, etc
Setup:
- New files:
- DBC files for PMU16 and PMU16-AS are now installed in the Documents/PMU/ folder
2022-03-28 Client: 57.0.1 beta / Firmware: 57.0
Client:
- Fixes:
- CANX Loader: fix for compound streams (LinkECU_GenericDash.canx is now imported properly)
- Improvements:
- The software code is now digitally signed with “ECUMASTER Sp. z o.o.” digital signature.
2021-12-29 / Client: 57.0 exp / Firmware: 57.0 exp
Note:
- Starting from 1st January 2022 all devices produced by ECUMASTER will have 12-digit serial numbers (until now 8-digit serial numbers have been used).
Firmware:
- New features:
- Added support for devices with 12-digit serial numbers
Client:
- New features:
- Added support for devices with 12-digit serial numbers
- Added firmware upgrade prompt when connecting the device for the first time to client software
- Added firmware upgrade prompt when opening the project file from newer firmware version
- Added “Offline firmware configuration selection” when loading project files from older firmware in offline mode (with CAN adapter not connected to PC)
- Added ‘Fixed frequency’ option for CSV exporter (GraphLog / Export icon / advanced exporter)
- Added board revision on Help / About screen
CAN Streams:
- New:
- Lotus_Elise.canx
- SCS_Delta_D800.canx
- BoschMotorsport_MS4Sport.canx
- Updated:
- EvoX.canx – fixed ‘c_gear’ channel
- EMU_BLACK.canx – added separate channels for virtual and parameter outputs
- Haltech.canx – added ‘checkEngineLight’ and ‘batteryLight’
2021-09-29 / Client: 56.0.2 exp / Firmware: 56.0 exp
Client:
- Improvements:
- – DBC Importer (v4-pmu):
- – An additional space before the ‘@’ character in the .DBC file is now handled correctly
- – The popup “Unit mapping file has been changed. Do you want to save it?” no longer appears if the unit mapping is not changed.
- – Signal multiplier and divider calculation has been improved
- Fixes:
- – A division by zero crash has been fixed (this bug could occur when the divider of CANbusInput
has been set to zero by a previous version of DBC Importer).
- – A division by zero crash has been fixed (this bug could occur when the divider of CANbusInput
2021-08-05 / Client: 56.0 exp / Firmware: 56.0 exp
Firmware:
- New features:
- – Delayed turning off (requires separate Battery 12V and Ignition Switch 12V wiring)
- – Use the F9 and type ‘Delayed turn off’ to put the pane of the current desktop:
- – Turn Off Minimal Time [seconds]
- – Turn Off Maximum Time [seconds]
- – Turn Off Channel (when this channel becomes high (non-zero) after Minimal Time the device will power off).
- – Channel ‘pmu.isTurningOff’ has been added to do custom actions
- – Switching the ignition switch back ON when Delayed Turning Off is used causes PMU to restart (it is possible after 0.5 seconds after starting the Delayed Turning Off procedure)
- Improvements:
- – A log file in the Internal Memory of PMU is properly closed when PMU is shutting down by the Ignition Switch (requires separate Battery 12V and Ignition Switch 12V wiring).
2021-07-05 / Client: 55.0.1 / Firmware: 55.0
Notes:
- – The firmware 55.0 and 55.0-exp are exactly the same firmware.
2021-06-07 / Client: 55.0.1 exp / Firmware: 55.0 exp
Client:
- Fixes:
- – Project Tree: Confirmation of Delete operation works properly for all buttons of Grayhill keypads
Ecumaster USBtoCAN:
- – Internal software updated to v15.1 (automatic update offered when starting the PMU Client).
This update improves the reliability of CAN communication with a PMU device.
2021-05-07 / Client: 55.0 exp / Firmware: 55.0 exp
Firmware:
- New features:
- – Added support for ‘5×2 Ecumaster (7 colors)’ keypad
- – Added support for ‘Emtron’ keypad
- – Added support for Backlight Intensity for Grayhill / Emtron / Motec/RaceGrade keypads
- – Switch element can now count downwards using channel “Input channel down” / “Trigger edge down”
- Improvements:
- – Changing Open Ceremony and Backlight Color now works on ‘2×2 Ecumaster RGB (7 colors)’ keypad
Client:
- Fixes:
- – Fixed keyboard width in the dialog for old “3 colors” keypads
2021-02-18 / Client: 53.5.1 / Firmware: 53.5
Client:
- Fixes:
- – The Client software no longer freezes when trying to download very long logs from PMU-16DL /
PMU-16AS internal memory.
- – The Client software no longer freezes when trying to download very long logs from PMU-16DL /
2020-10-05 / Client: 53.5 / Firmware: 53.5
Firmware:
- Fixes:
- – The first PWM-enabled output could be accidentally turned off or activated at DC=100% (regression from version 52.2)
2020-08-07 / Client: 53.1.1 exp / Firmware: 53.1 exp
Firmware:
- Fixes:
- – CAN Compound Streams: fixed frame corruption when frames with the same ID, but with index not defined by the project appears on the bus
Client:
- Fixes:
- – Editing the Hysteresis operation works again (fixed regression from version 53.0)
2020-05-11 / Client: 53.0 exp / Firmware: 53.0 exp
Firmware:
- New features:
- – Toggle operation now has two new optional channels:
- – “Set channel” to set value to 1
- – “Reset channel” to reset value to 0
2020-04-10 / Client: 52.3.4 / Firmware: 52.3
Notes:
- – The firmware 52.3 and 52.3-beta are exactly the same firmware.
2020-01-27 / Client: 52.3.4 beta / Firmware: 52.3 beta
Client:
- Fixes:
- – The Client software works again on Windows XP (fixed regression from version 52.2)
2020-01-21 / Client: 52.3.2 beta / Firmware: 52.3 beta
Client:
- Fixes:
- – DBC Importer: Proper importing of big-endian signals when bitPosition/bitCount is not multiple of 8 bits.
- – Fixed device crashes after firmware upgrade when too many logged channels were used.
- – Fixed overlapping of LED indicators on the status bar when more than 100% DPI scale was used
CAN Streams:
- New:
- – Electronics_Limited_ME1_2.canx
- – M11_Korvet.canx
- – VAG_MED91.canx
- Updated:
- – Motec_M1.canx: channels c_Driver_Switch1..6 and c_Driver_Rotary_Switch1..8 added
- – Motec M1: CAN Input c_Fuel_Used_M1 changed to ecu.usedFuel
- – Pectel SQ 6: CAN Input c_Fuel_Used_ecu changed to ecu.usedFuel
- – EMU Black: CAN Input ecu.usedFuel added
2020-01-03 / Client: 52.3.1 beta / Firmware: 52.3 beta
Client:
- Fixes:
- – Fixed improper “Only pins with same current rating (e.g. 25A and 25A) can be linked together.” message.
2019-12-27 / Client: 52.3 beta / Firmware: 52.3 beta
Firmware:
- Fixes:
- – Fixed synchronization problems when sending/receiving frames to/from CAN network.
Client:
- Improvements:
- – DBC Importer: improved signal importing for factors 0.2, 0.5 and similar.
- Fixes:
- – The client now properly recognizes files saved in an earlier version as being non-autosport (bug in the Client 52.2).
- Changes:
- – The Client is now entering OFFLINE mode when opening the project file directly from the Explorer. This change has been made to protect the project in memory of the connected device.
2019-12-16 / Client: 52.2 beta / Firmware: 52.2 beta
Firmware:
- New features:
- – PMU-16 AS autosport version support:
- – 6 additional low-side outputs
- – Higher current rating for high-side outputs (2 x 40 Amps and 14 x 25 Amps)
- – Up to 10 outputs can be PWM modulated – even the low-side outputs
- Improvements:
- – The frequency of PWM output can now be changed while it’s already active
- – PWM DC Control now works properly for the 1%-99% range
- – DC% log channel ‘o_output.dc’ is now calculated more precisely.
- Changes:
- – PWM DC Control step is now 1%, no matter how the ‘out of’ denominator is specified.
- Fixes:
- – The states of the outputs are properly handled when deleting / moving up/down (when working with connected device)
Note: This firmware 52.2 supports all the PMU-16 models: PMU-16, PMU-16 DL, PMU-16 AS
Client:
- Improvements:
- – CANbus ID=0x000 is now allowed for CANbus Message Object and CANbus Export
- Fixes:
- – Expanding/colapsing the CANbus Message Object in ProjectTree no longer resets every CAN Input in the device
- Changes:
- – Hysteresis operation now accept two real constants (no need to multiply by 10/100/1000 anymore)
2019-09-11 / Client: 50.0.2 beta / Firmware: 50.0 beta
Client:
- New features:
- – Support for Peak PCAN-Ethernet Gateway.
- Improvements:
- – Added list of predefined sensors (Analog Input dialog – Wizard button)
- Fixes:
- – Missing channels from EMU_B
2019-05-31 / Client: 50.0 BETA / Firmware: 50.0 BETA
Firmware:
(NOTE: Firmware can be upgraded using File / UpgradeFirmware command from Client menu)
- New features:
- Timers
- Calibrated Analog Sensors
- Decimal places and units support in Numbers, AnalogInputs and Tables
- Support for Compound CAN streams (4bit, 8bit, 16bit)
- New “Changed” operation for logical Functions
- Improvements:
- Bitfield can be assigned as the channel of the Table
- Changes:
- Evaluation order of elements has been changed to reflect order in the Project Tree. Now the evaluation order is the same as in the ADU.
Client:
- New features:
- UI system has been adopted from the ADU – use F9 to add a pane to the desktop
- Duplicate button in the ProjectTree
- Save .CANX in the CANbusMob window
- Widths of columns are preserved: ProjectTree, TextLog, OutputMonitor, AnalogMonitor, VariablesInspector
- GraphLog: Shift+S toggles between lines and points+lines
- Improvements:
- Channels added to Custom 1/2/3 Log windows are now preserved when upgrading the firmware
- Changed name of the F5 shortcut in the menu to “Reset project in the PMU-16”
- Delete command from ProjectTree is now working a lot faster
- Bitfield can be assigned as the channel of the Table (requires firmware 50.0 or later)
- Changes:
- Changed MinimalClientVersion required to load a project. You will not be able to load a project saved by this Client software in its previous version. Please backup your project.
- The desktops layout file format has been changed and the extension of such files was renamed to .pmulayout2
- .CANX files moved to PMU\CANX\ folder and user .CANX files moved to PMU\CANX\USER\ folder
- Fixes:
- Exporting the CSV files no longer causes a crash for some input data
- Important note:
- Version number scheme of the Client has been changed: Now it’s always FirmwareMajor.FirmwareMinor.ClientFixes (ClientFixes is omitted when zero) e.g. 50.0.1
- FirmwareMajor changes when new firmware introduces new settings in the Client
- FirmwareMinor changes on every fix in the new firmware that NOT introduces new settings
- ClientFixes changes on every Client only update
- CAN streams:
- Added AbitM11
- Added ECUMASTER Battery Isolator
- Added ECUMASTER CAN Switchboard V3
- Added Emerald
- Added Haltech
- Added Holley_HEFI
- Added Hondata
- Added KMS MD56
- Added LinkECU GenericDash
- Added MBE
- Added Motec M84 to PDM
- Added Trijekt
- Several .CANX files has been updated
ECU Master USBtoCAN:
- Internal software updated to v14.0 (automatic update offered when starting the PMU Client). This software improves compatibility with an older version of PMU/ADU Client.
2019-04-25 / Client: 0.045 / Firmware: 0.045
Firmware:
- New features:
- Added support for RaceGrade / MoTeC keypad.
- Added new type of button ‘Indicator3’ to control individual LEDs (Grayhill / Racegrade / MoTeC keypads).
Client:
- Changes:
- Changed MinimalClientVersion required to load project. You will not be able to load project saved by this Client software in its previous version. Please backup your project.
- The keypads are now configured using the CANopen node ID (default 0x15 for Ecumaster keypads) instead of the Buttons ID. This is exactly the same way as in the Light Client.
2019-04-17 / Client: 0.044.6.1 / Firmware: 0.044.6
Client:
- Fixes:
- Importing from CANX file more than 8 CANbus Mobs per CAN channel no longer leads to the project corruptions.
2019-04-09 / Client: 0.044.6 Firmware: 0.044.6
Firmware:
- Fixes:
- Changing the speed of the CAN2 no longer causes Bit Stuffing Errors.
- PMU device no longer freezes when internal data flash memory is corrupted. An appropriate
- message will appear when connecting to the Client software.
Client:
- Improvements:
- Improved support for Window XP
Fixes:
- Fixed another timeout bug in Ecumaster USBtoCAN update process (Windows XP).
- Peak CAN interface is working on Windows XP
Ecumaster USBtoCAN:
- Internal software updated to v0.12 (automatic update offered when starting the PMU Client).
2019-03-26 / Client: 0.044.5 Firmware: 0.044.4
Improvements:
- Names of documents on the menu bar are properly handled when working with multiple PMUs
- More space between names of devices on the toolbar.
- Performance of CAN input channels improved even in high CAN traffic.
Fixes:
- Grayhill 5×4 and 4×5 keypad: bottom row of buttons behaves as expected
- Fixed timeout bug in Ecumaster USBtoCAN update process.
2019-01-02 / Client: 0.044.2 / Firmware: 0.044.0
Fixes:
- Encoding issue no longer causes a crash when working with the Finnish version of Windows.
2018-12-07 / Client: 0.044.0 / Firmware: 0.044.0
New features:
- Support for new ‘2×2 Ecumaster (7 colors)’ keypad Improvements:
- Master Retry now resets only overcurrent and undercurrent outputs. (Ecumaster ADU no longer restarts on Master Retry if connected to PMU output.)
- Master Retry does not reset the requested value of the output (“o_output = k_key or o_output” will preserve its state).
Fixes:
- Switching access to the CAN between ADU / PMU / LightClient works in all cases.
2018-11-20 / Client: 0.043.1 / Firmware: 0.043.0
New CAN Streams: (Use: Import CANX from Project Tree)
- AEM
- DTA Fast S series
- Emtron
- Evo X
- Life Racing
- MaxxECU
- Megasquirt 2 & 3
- Syvecs
2018-10-15 / Client: 0.043.0 / Firmware: 0.043.0
New features:
- Support for Grayhill keypads added (CANopen version)
Fixes:
- Fixed PMU freeze when changing CAN2 speed when CAN bus line has different speed.
- Diagnostics channels pmu.diag.can1/2.rxErrors/txErrors work as expected
- Timeouts of CANbus massage objects work properly in all situations
2018-09-20 / Client: 0.042.8 / Firmware: 0.042.5
New features:
- Switching CAN adapter between ADU and PMU. You can work with two clients at the same time and switch adapter between them. ADU Client 50.1 or newer is required
2018-09-19 / Client: 0.042.7 / Firmware: 0.042.5
Improvements:
- Ecumaster USBtoCAN: internal software updated to v0.10 (automatic update offered when starting the PMU Client).
- Status bar now shows CAN1 / CAN2 status (like in the ADU Client).
2018-04-09 / Client: 0.042.5 / Firmware: 0.042.5
Fixes:
- Function evaluation when “True delay” and “False delay” parameters were both non-zero fixed.
- Output voltage is now properly measured on PMU HW3 model.
2018-02-27 / Client: 0.042.1 / Firmware: 0.042.1
New features:
- Support for new ‘6×2 Ecumaster (7 colors)’ keypad
- Changing back light color for 7-colors Ecumaster keyboards (Use More settings button in keyboard setup dialog)
- Delays in IsTrue/isFalse/comparision operations. Examples:
- a) channel is 1, when c_ecu_rpm > 2000 for 5s
- b) channel is 1, when c_csb_switch1 is holded down for 1s
- Pulse operation – retrigger (retriggering pulse in the middle of active pulse)
New CAN Streams: (Use: Import CANX from Project Tree)
- Motec M1 ECU
- ViPec/Link ECU (Generic Dash 2)
- Ecumaster EGTtoCAN
2018-01-08 / Client: 0.035.2 / Firmware: 0.035.0
Fixes:
- (client) Fixed crash when creating/editing Switch (bug since client version 0.034.1)
2018-01-02 / Client: 0.035.1 / Firmware: 0.035.0
Fixes:
- (client) Fixed crash when editing CANbus Mob on firmware lower than 0.035
2017-12-21 / Client: 0.035.0 / Firmware: 0.035.0
New features:
- Support for new ‘4×2 Ecumaster (7 colors)’ keypad
- Support for Pectel SQ6 CAN stream (Use Import CANX from Project Tree)
Improvements:
- Now CANbus Inputs are automatically grouped by CANbus Mobs (firmware 0.035 required)
- Maximum length of names in a project increased to 30 characters (up from 20) – works with any
firmware
- Heating model for outputs is now calculated using filtered current. It fixes some Overcurrent situation when Inrush current was equal to Max current.
Fixes:
- EMU_BLACK.canx – fixed c_ecu_injPW and c_ecu_ignAng
2017-12-07 / Client: 0.034.1 / Firmware: 0.034.0
This is Client only update. Contains firmware 0.034.0, the most recent firmware. The firmware 0.034.0 fixes CAN terminator issues on CAN1 / CAN2. Now it works as documented:
- CAN1: no terminator (USBtoCAN termination or external terminator on CAN1 required)
- CAN2: user selectable terminator (Treeview/PMU/CANbus setup)
Improvements:
- Added c_ecu_cltError to EMU_BLACK.CANX
- Generate Pinout command: added Min current, Max current, Inrush current / Inrush time for outputs (menubar: Devices/Generate Pinout)
Fixes:
- Fixed bug with minimum and maximum value when creating the Table.
- Password is now correctly replaced with (fixed regression from version 0.033)
2017-12-07 / Client: 0.034.0 / Firmware: 0.034.0
The firmware 0.034.0 fixes CAN terminator issues on CAN1 / CAN2. Now it works as documented:
- CAN1: no terminator (USBtoCAN termination or external terminator on CAN1 required)
- CAN2: user selectable terminator (Treeview/PMU/CANbus setup)
Improvements:
- Switch element – range has been extended to 0..255 (up from 0..4)
- Default frequency of some channels has been increased:
- pmu.o?.voltage now logged at 25Hz (up from 5Hz)
- pmu.a?.voltage now logged at 25Hz (up from 5Hz)
- pmu.acc*/pmu.gyro* now logged at 25Hz (up from 5Hz)
Fixes:
- Fixed program freezing after 5 hours of working
- Fixed terminator issues on CAN1 / CAN2
- Project Tree: Fixed channel corruption when Move up/Move down/Delete command was used and project used output.dc, output.timeAboveMax or mob.timeout channels.
2017-11-20 / Client: 0.033.0 / Firmware: 0.033.0
New Features:
- User-defined tables (2D / 3D, variable size, each axis can be user-selectable), can be used as PWM tables
Improvements:
- Wipers: “Brake delay time” added to allow fine-tuning of the wiper parking spot. The wiper motor is not powered in this state.
- PWM: When the Duty cycle is ZERO, the output is completely turned off.
- PWM can be activated even if the output is Active. No need to turn off / turn on the output.
- Project Tree: added keyboard shortcut for Move up / Move down – Alt+UpArrow / Alt+DownArrow
- Ecumaster USBtoCAN device: reliability and performance improvements (USBtoCAN software update to v0.5 is offered automatically when starting PMU Client).
- Parameter panel and Status bar are properly scaled on high-DPI devices.
Fixes:
- Fixed rare crash related to “Use client data”/“Get data from PMU” when working with 2 PMUs.
- Fixed crash related to the escape key pressed in Canbus Mob creation invoked from Canbus Input dialog
- Fixed crash when exiting application in Offline mode
2017-10-13 / Client: 0.031.1 / Firmware: 0.031.0
Fixes:
- Fixed connection problems between Ecumaster USBtoCAN and the latest firmware 0.031.0
2017-10-04 / Client: 0.031.0 / Firmware: 0.031.0
New Features:
- (firmware) Improved Power Control Model. Support for devices with delayed activation (such a ABS module in the car).
- (firmware) Password protection
- Added ability to choose “Use client data” or “Get data from PMU” if data are different when
connecting
- Autoscale on GraphLog (requires firmware 0.030.0 or later)
- Export GraphLog data to Excel (CSV file format); also works with selection
- Display filter can be assigned to each GraphLog channel (GraphLog – right mouse button – Properties). Useful for smoothing accelerometer data. Turned on by default for two pmu.boardTemperatures.
- (firmware) Channels can be multiplied by constant *1, *10, *100, *1000, *custom, raw in
CANbusExport
- (firmware) Each subchannel can be multiplied by constant *1, *10, *100, *1000, raw in Number
- (firmware) Decimal places in Canbus Input – for example, c_pmu.batteryVoltage is now 12,5V instead of 12500
- Some channel can be viewed as bitfields (pmu.can1.state, pmu.can2.state, pmu.outActiveMask, pmu.outFaultMask, pmu.outOvercurrentMask, pmu.outShutdownMask) (requires firmware 0.031.0 or newer)
- (firmware) Number: added Modulo operation (reminder)
- (firmware) Number: added Lookup operations (for simple lookup tables; 2,3 or 4 entries)
Improvements:
- Reconnect command (Shift+Ctrl+B) – two PMU can be turned on one after another
- Hot unplug/plugin Ecumaster USBtoCAN possible
- When downloading log from DL memory of PMU, the file is saved to Logs\ directory with date/time included in file name (e.g. Logs\20170622_1703_12.pmulog)
- Added warning message when one of PC<=>PMU communications CAN IDs is used in CANbus Export (IDs 0x12-0x17 on CAN1).
- GraphLog – value axis has now variable number of helper lines
- GraphLog – current value displayed on each graph
- Wipers dialog – added check to ensure that Park Switch could be used only with output O8.
- Logs saved on PC: It’s now possible to analyze logs, even if some modification was made to the project. Only names of elements must match.
- GraphLog min/max ranges automatically configured for CanbusInputs, AnalogInputs, keyboard
buttons
- Pausing the GraphLog works as expected in all situations
- Channels outside of 8 bytes in Canbus Export are now disabled for easier understanding.
- EMU_BLACK.CANX updated to support decimal places (for example: c_ecu_lambda from EMU/BLACK has now fractional part) – (requires firmware 0.031.0 or newer)
- PMU.CANX updated to support decimal places (requires firmware 0.031.0 or newer)
- GraphLog: Inrush current and Max current lines visible on o_name.current channels
Fixes:
- – Constant -16383 can be assigned to any channel (as stated in the documentation).
- – Fixed bug when some u16/s16 empty channel in the middle of Canbus Export was not properly saved to the device.
- – GraphLog now shares the same configuration for all desktops
- – Sometimes during connecting Client showed that PMU data are corrupted and asked for restore. This rare bug has been fixed.
- – When saving .pmulog file, the debug file .pmulograw is no longer saved
- – Fixed focus problem on some popup windows, when clicked outside the popup
2017-07-19 / Client: 0.026.6 exp / Firmware: 0.026.6
Fixes:
- (firmware) Fixed proper activation of brake circuit for wipers. Wipers should park as expected now.
- (client) Fixed rare crash after firmware upgrade.
- (client) Fixed crash when using popupMenu on empty GraphLog
2017-07-04 / Client: 0.026.5 exp / Firmware: 0.026.2
This is Client only update. Contains firmware 0.026.2, the most recent compatible firmware.
Fixes:
- Fixed Group Selection command (Ctrl+G or button “Group”). The names of all elements in the project were corrupted after this command.
2017-06-08 / Client: 0.026.2 exp / Firmware: 0.026.2
Fixes:
- (firmware) Fixed not responding buttons on Ecumaster keyboard
- Fixed crash when using Undo (Ctrl+Z) too deeply after Firmware Upgrade
Improvements:
- Ecumaster USBtoCAN – performance improved on slower computers
2017-05-09 / Client: 0.026.0 exp / Firmware: 0.026.0
New Features:
- (firmware) CAN 2.0B support with extended ID (29 bits)
Improvements:
- Improved reliability of client on slow computers
Fixes:
- Fixed crash when saving some projects
- Fixed loading of projects containing channel with dot character (e.g. c_pmu.a3.voltage)
2017-04-24 / Client: 0.025.0 exp /Firmware: 0.025.0
Improvements:
- (firmware) CANbus Input: Timeout value and Default value separated.
Fixes:
- Fixed Ecumaster USBtoCAN rare disconnection bug. USBtoCAN software update is offered automatically when starting PMU Client.
