TE Motorsport by TAG Engineering Group. | ECU Master DATA Master Analysis Change Log

DATA Master Change Log (Incl. Tested Version)

我們一直不斷的進行更完善的功能更新以及問題修復,目的是希望能提供更棒更優異的使用體驗,以下更新記錄包含了先行版(測試版),對此可能會有部分功能不穩定,如遇到使用上的功能問題,請聯繫客服並嘗試退回之前的版本進行使用。

Service Mail : tech@tag-parts.com

2024-08-23 Client: 2024.5.1

Data:

  • Fixes:
    • Fixed incorrect handling of GPS data from ADU version 104.0
    • Fixed an issue where logs saved in ADU software version 104.0 and firmware 92.x were incorrectly loaded
    • Fixed a crash that occurred when attempting to save a project to a nonexistent path

2024-07-26 Client: 2024.5

Data:

  • New features:
    • Reports introduced: Reports can be used to automatically identify specific situations in the log
    • Support of logs from EMU PRO version 111.0
  • Improvements:
    • Excluded laps are saved in the .dmdata file and restored when the file is opened again
    • After editing drag runs in the Lap Editor, the segment split is rechecked
  • Fixes:
    • Fixed issues with drag runs ending too early
    • Fixed issue with Math tree groups not clearing when loading a new project

Visualizations:

  • New features:
    • New context help available (question mark icon or F1)
  • Improvements:
    • Updated default desktop layouts
  • Fixes:
    • Fixed incorrect drawing of enum channels from EMU PRO
    • Fixed incorrect Run Chart drawing for negative values

2024-04-19 Client: 2024.4

Data:

  • New features:
    • Introduced full GPS support for logs other than ADU or for custom GPS channels. It’s done via the @GPS_LATITUDE and @GPS_LONGITUDE aliases, that the user can attach the channels to
  • Improvements:
    • Lap Editor: start point move allowed only when GPS and speed channels are defined
    • Importing an archive: you can now select the videos to synchronize as in the original project
    • Old project saves when opening a new project
  • Fixes:
    • Fixed laps being stuck as excluded
    • When starting a new project, it no longer inherits the mathematical file and the video from the previously worked on
    • Fixed an issue with incorrect values showing in the log and during the CSV export with the EMU PRO user-defined channels
    • Fixed data corruption when reordering logs or deleting a single file
    • Fixed a crash when comparing two laps from different files and using the filtering function of the Graph Log
    • • Fixed issues with lap times showing 0 when the Reference Track is in use. Too short segments were corrupting lap times
    • Fixed a bug causing unintended behavior when using the user split in case of multiple logs loaded
    • Fixed a rare bug when loading a new log corrupted the decimal places in the math channels
    • Fixed a bug which enabled the user to start a new project with a corrupted desktop
  • Changes:
    • Default speed channel source for distance calculation changed to @SPEED alias to obtain maximum versatility

Visualizations:

  • New features:
    • Table Builder added. The Table Builder offers a data visualization using a maplike table.
    • You can generate a Table Builder from a Scatter Plot and vice versa
    • Graph log and favorite panels can be added from menubar and toolbar
  • Improvements:
    • Axis range works correctly on thermal channels
    • Focus on log added for consistency in Log Manager panel behavior
  • Fixes:
    • Fixed an issue with some panels not refreshing automatically
    • Fixed issue with Scatter Plot state not being assigned properly when duplicating a tab
    • Fix for Track Window scaling

2023-11-02 Client: 2023.6.2

Data:

  • Fixes:
    • PMU log files from version 92.0 load correctly.

Visualizations:

  • Improvements:
    • The improper time

2023-10-06 Client: 2023.6.1

Data:

  • Fixes:
    • Fixed a crash when an alarm is checked on an absent math channel

2023-09-29 Client: 2023.6

General:

  • Improvements:
    • Reduced application startup time

Data:

  • Improvements:
    • Improved log loading speed
    • Support of logs from PMU version 92.0
    • Enhanced Lap Editor with significant stability and interface improvements
  • Fixes:
    • Resolved an issue displaying incorrect values during comparisons of drag runs with different distance lengths
    • Corrected a bug causing bitfield channels to export incorrectly to CSV files

Visualizations:

  • Changes:
    • Enabled reference track management from GPS/Track map, not limited to Lap Editor
  • Fixes:
    • Addressed the problem of software locking when toggling full-size panels with DPI scaling
    • Fixed unexpected behavior when adding panels in full-size mode

2023-08-25 Client: 2023.5

General:

  • Changes:
    • Log manager relocated to the side panel. Press Ctrl+L to toggle it on and off.

Data:

  • New features:
    • Lap splitting by speed introduced for ECU logs in circuit projects
    • Added support for .LRV video files
    • Added support for ADU hill climb logs
    • All channels can now be exported to CSV
    • @SPEED alias can be selected as a channel for time vs. distance calculations when comapring laps
  • Improvements:
    • Invalid laps are now automatically excluded

Visualizations:

  • New features:
    • Added the ability to full-size a single panel (F6 or Tab+Space)
  • Improvements:
    • Enhanced contrast and visibility
  • Fixes:
    • Resolved a bug causing a crash when more than 32 channels were added to the same axis.
    • Fixed an issue where dyno projects got stuck in the distance domain
    • Resolved an issue with scatter plot axes crashing when using an unresolved alias

2023-06-12 Client: 2023.4.1

Data:

  • Fixes
    • Fixed math constant issue with capital letters in the name returning 0
    • Resolved software crashing when creating a reference track without laps in Rally project type

2023-06-07 Client: 2023.4

Data:

  • Improvements:
    • Support of logs from EMU PRO version 98.0
  • Fixes
    • Fixed occasional software crashes when loading multiple logs
    • Resolved issues with loading short logs into the Rally project

2023-05-05 Client: 2023.3

Data:

  • Improvements:
    • Full support of user-defined colours
  • Fixes:
    • The issue that caused the incorrect log duration to display in the Log Manager has been resolved

Visualizations:

  • Improvements
    • Coach mode refresh rate increased for a smoother drawing experience

2023-04-24 Client: 2023.2

General:

  • Fixes:
    • Fixed the issue preventing Graph Log keyboard shortcuts customization

Data:

  • Fixes:
    • Added support for EMU BLACK logs created from version 2.162B

Visualizations:

  • Fixes
    • Fixed an issue with manual axis ranges not loading properly
    • Fixed a Graph Log issue with active axis not changing after clicking the channel name
    • Fixed a Scatter Plot issue unabling the user to change the axis range for alias channels

2023-04-21 Client: 2023.1

General:

  • New features:
    • Keyboard shortcuts can be customized
  • Improvements:
    • Overall dark mode improvements
    • Full DPI scaling support

Data:

  • Improvements:
    • Major improvement of the GoPro synchronization algorithm
    • Added support of EMU PRO logs from version 90.0 upwards
  • Fixes:
    • Fixed the issue with the preview of the CSV not generating properly
    • Fixed the issue with the CSV export crashing in case of large files
    • Channel colors are handled properly
  • Changes:
    • At the moment, it is not possible to add or remove channel colors
    • Discontinued support of older EMU PRO logs (below version 90.0)

Visualizations:

  • New features:
    • Trace added to the scatter plot
  • Improvements:
    • Changed the definition of minimum and maximum values for the channel. Instead of applying these properties to each channel individually, they are now defined for the individual Graph Log axis
    • Each axis on the Scatter Plot can be configured individually

2022-11-29 Client: 2022.12

Data:

  • New features:
    • User data: custom log split and bookmarks are now saved in .dmdata files
    • Timeshift function added to the math channels
  • Improvements:
    • Bookmarks can be added, edited and deleted from the log. The user can select the severity of the bookmark.
  • Fixes:
    • Fixed a bug with aliases not loading correctly in rare cases
  • Changes:
    • Adjusted channel colours to improve visibility

Visualizations:

  • New features:
    • Reference cursor added to the Graph Log
    • Bookmark Overview panel added
  • Fixes:
    • Selection length/start text handled properly in GraphLogWindow when changed from the keyboard
    • Fixed an inconsistent cursor position between desktops
    • The track map overlay now working properly in the video
    • The scatter plot not refreshing when the cursor moved from the video

2022-080-29 Client: 2022.10

Data:

  • New features:
    • Added a possibility to exclude/include all laps in the log
  • Improvements:
    • Channels with no data logged can be hidden in the channel select window
    • Cl.timeSlip calculation algorithm improved to avoid artefacts at the end of the lap
    • Default aliases can be edited – not compatible with previous versions
    • Channel properties (colour, filtering etc.) are saved in the project file
  • Fixes:
    • Fixed stability issue causing random crashes of video
    • Fixed an issue with video randomly freezing in slow motion
    • Fixed issues with min/max limits of EMU
    • Black/Classic channels
  • Changes:
    • User-defined aliases created in previous versions will not be supported
    • Added more default aliases

Visualizations:

  • New features:
    • Added a possibility to overlay data over video – 2 layouts currently supported

2022-06-29 Client: 2022.8

Data:

  • New features:
    • Added support of EMU Classic log files (.emulog, .bgc)
    • .dmproj and .dmarchive files can be opened directly from the desktop
  • Improvements:
    • After successfully packaging a project, a message box is displayed
  • Fixes:
    • Fixed no offset bug when loading multiple files from EMU Black
    • Fixed issue with longer drag runs not splitting correctly
    • Fixed issue with math channel frequencies not saving properly
    • Fixed bug when starting lap is not equal 0
    • Fixed bug with math channels freezing
  • Changes:
    • Laps generated from the reference track can’t be split/deleted
    • File description changed to DATA_MASTER

Visualizations:

  • New features:
    • The Channel Report panel added
    • Added a text box showing the current offset in the Video panel (manual synchronization mode)
  • Improvements:
    • A grid can be toggled in the Graph Log
    • Added shortcut to toggle between time and distance axis
    • By clicking the segment label you can focus on segment in the Graph Log
    • When comparing laps, the channel filtering remains active in the Graph Log
    • Button labels in manual synchronization changed
  • Fixes:
    • Fixed issue with filtering alias channels in the Graph Log
    • Fixed issue with the cursor not updating when scrolling in the Graph Log
